PLC Granite Marble Quarry Stone Diamond Wire Saw Cutting Machine
YLW-75G-55G-45G-37G
This machine adopts double inverter stepless speed regulation,
while cutting, it can achieve constant tension wire cutting process
and automatic control, automatic control system can be realized
according to the speed of walking machine change science to adjust
the load, which is always in the best working state of diamond
wire.
Technical Parameter
| Parameter | Unit | YLW-37G | YLW-45G | YLW-55G | YLW-75G |
| Main Motor | kw | 37 | 45 | 55 | 75 |
| Wire Speed | m/s | 0-40 |
| Walking Speed | m/h | 0-30 | 0-160 |
| Adjustment Dimension | mm | 450 | 500 |
| Cutting Distance | mm | 1750 | 2030 |
| Rotation Angle | ° | 360 (electric) |
| Outline Dimension | mm | 2113*1361*1410 | 2336*1536*1670 |
| Max Wire Length | m | 60 | 80 | 100 | 120 |
| Gross Weight | t | 2 | 2.1 | 3 | 3.2 |
Factory Overviews
Fujian UNIQUE Machinery Co.Ltd was established in 1985 and have
been dedicated to the development and producing of a serious of
column making machine,wire saw stone cutting machine,block trimming
machine, bridge saw cutting machine, profiling stone cutting
machine etc.
With the rapid development of company ,we have passed the ISO9001
verifing, CE, and won many honory tiles include International Gold
Plant Quality Award etc. We keep " Advanced Tecnology and High
Quality" as our aim. We have developed a range of 'UNIQUE' Brand
special stone shape processing machines.Certifications
Our Service* We can provide Machine Testing Video and will be strict inspected
and testing for every machines before shipping out.
* After-sales service 24 hour on line. We will service staff
training, so that continuously improve the overall quality of
service.
* We are responsible for receiving and processing customers on
product quality and service quality complaints; We have
professional and technical personnel to guide the installation and
commissioning of your machine and operator training.
Shipping
FAQ
Q: How to place order to your company?
A: 1. Inquiry-Professional quotation.
2. Confirm the price, lead time, logo, payment term etc.
3. Xianda sales send the Proforma Invoice with seal.
4. Customers make the payment as a deposit and send us Bank
receipt.
5. Sales confirm the receipt of down payment . After approval, we
will arrange the production & inform the estimated time.
Q: How is After-sales Service Provided?
A: Engineer can dispatch for assembly machinery
Q: Are you Manufacture Factory?
A: Yes,that we are the stone machinery factory for over 30 years.
